01 Engine 01 15 Rotating parts
Measuring piston - liner clearance – Measure the piston's diameter (See: "Measuring the piston skirt"). – Measure the liner bore on a plane parallel to the piston pin (A) and (B), and at 90° in respect of the piston pin (C) and (D).
A
C
B
D
– Compare A, B, C and D to determine whether the liner is conical or oval. – Compare the inner diameter of the liner with the external diameter of the piston skirt. Change the piston and liner if the values exceed those specified. Values indicated: Liner inner diameter..........................106,48 - 106,52 mm Maximum out-of-roundness at top of liner .......... 0,05 mm Maximum taper at top of liner ............................. 0,05 mm Piston - Cylinder liner clearance ...............0,08 - 0,15 mm
