01 Engine 01 10 Engine sump
Disassembling the liners – Use tool n°77 0138 818 0 to measure height (A) of each liner at the 1, 5, 7 and 11 o'clock positions, seen from the back of the engine.
A
Important: Tighten the screws and washers to obtain a precise measurement of the liner height. Values indicated: Height above the block .........................0,030 - 0,100 mm Maximum acceptable difference between the same or between 2 adjacent cylinders ............................. 0,05 mm – Remove the liner adjustment screws and washers fastened to the block. Important: Do not mark the top of the piston. – Before disassembly, number the liners and the pistons. Mark the front of the liners to reassemble them in the right direction.
Fig. 21
121hsm51
Important: Always maintain the pistons and liners paired. The liners must be returned to their original bore. – Pull out the liners from the cylinder block using tool (A) Nr.60 0500 550 4.
A
121hsm52
32
Arion 430-410 – 01.2010 – GB
Fig. 22
