01 Engine 01 02 Complete assembly
Operation n° 25 – Sling the engine on 4 points to balance the load. Note: The engine has a weight of about 550 kg. – Remove the screws from the (1) clutch casing.
1
101msm99
Fig. 26
101hsm05
Fig. 27
Operation n° 26 Important: Before removing the engine, check that all elements are disconnected properly. – Removing the engine. – Lay the engine on flat and clean ground. – Remove all external engine elements (Starter, Alternator...).
Refitting the complete engine – Refit all external engine elements (Starter, Alternator...). – Refit the engine elements and controls by performing the above operations in reverse sequence. – Fill the A/C unit (see chapter 12 40). – Fill the engine and the cooling circuit with oil (see operating manual). – All tightening torques of the front chassis on the engine and the engine on the clutch casing are in part "03 00".
Arion 430-410 – 01.2010 – GB
21
