Steering and Body This section has been organized into sub-sections for servicing steering and body components; however, some components may vary from model to model. The technician should use discretion and sound judgment when removing and installing components. NOTE: Whenever a part is worn excessively, cracked, or damaged in any way, replacement is necessary.
SPECIAL TOOLS
0747-529
A special tool must be available to the technician when servicing the steering and body systems. Description
9000
p/n
Shock Spring Removal Tool
0644-057
Handlebar Stand
5639-152
Steering Post Stand
5639-946
NOTE: Special tools are available from the Arctic Cat Service Parts Department.
Steering Post
0746-791
REMOVING (Standard) To remove the access panel and hood, use the following procedure: 1. Remove the hairpin clip from the pin located at the front of the access panel. Move the panel up and off the pin; then swing the panel all the way out and unhinge the panel from the lower console. 2. Remove all six torx-head screws securing the hood. 5000
3. Locate the hood harness connector (located under the center vent between the intake vents) and unplug the connector; then move the hood slightly forward and remove the hood. NOTE: On the 9000, first unhook the rubber straps securing the air filter housing to the intake plenum of the hood; then move the hood slightly forward and remove the hood.
4. Remove the push rivets securing the right-side steering boot to the chassis. This allows access to the two nuts securing the bottom of the steering post.
0746-792 XM134A
5. Remove the nut (A) securing the bottom of the existing steering post to the steering stop bracket; then remove the nut (B) securing the steering tie rod assembly to the steering post. Discard both nuts.
