WorkBoat Awards
SPECIFICATIONS
Owner: Red and White Fleet Builder: All American Marine Designer: Teknicraft Design Ltd. Mission: Harbor tour and event charter vessel Length: 128' Beam: 30' Main Propulsion: (2) Cummins QSL9 Tier 3, 410 hp @ 2,100 rpm; (2) Corvus 80-kWh lithium-ion battery pack; (2) BAE Systems HybriGen propulsion system with generator, control system, and AC electric traction motor Propeller: (2) VeemStar fixed pitch propeller, 48" dia., 36.5" pitch Marine Gear: Twin Disc, 3:1 Passengers/Crew: 600, 6 Steering System: Jastram HPU-1225PF-24VD three-station jog-lever hydraulic power Speed (knots): 10 cruise, 12 loaded Controls: Twin Disc EC300 propulsion controls, Glendinning EEC-3 electronic control stations Hull Material: Aluminum full displacement type monohull Capacities (gals.): Fuel 2,200 (in four 550-gal. fuel tanks); potable water, 1,000 Navigation/Communications: 3-station jog lever hydraulic power steering system, consisting of a Jastram HPU-1225PF-24VD power unit with an electric driven hydraulic pump
Red and White will also be adding 1.5 million sq. ft. of solar panels to provide totally clean electricity to the battery systems. “If we need to, we will also take power off the grid, but that’s hydropower here in San Francisco, so we’ll be getting clean power from the grid and from solar, so we’ll have a really clean boat,” said Escher. With a properly sized bank of batteries shoreside, the recharging of the Enhydra, even with more batteries, is envisioned to take just eight or nine minutes. “All we are doing is copying the Norwegians,” said Escher. “They’ve been doing some fast charging for several years on allelectric ferries.” “Shore-based power is much more efficient and has lower carbon content than the stuff that comes from a diesel,” said Allan Grant of Corvus Energy in Vancouver, British Columbia. “It’s also less expensive. 4
Accommodations: 92 passenger seats on main deck (interior); 226 seats on the second deck (106 interior, 120 exterior); 108 passenger seats (exterior) on the third deck with an upper deck capacity of 300 passengers Electronics: (2) Furuno Black Box MFD (TZTBB) processor; Ultra high definition (UHD) digital 6-kW radar (DRS6A) with 4' open array; NavNet 3D 2" digital radome radar (DFF-1); Black Box echosounder module for NavNet 3D; Furuno (SS60-SLTD) thru-hull transducer; GPS sensor (GP330)-NMEA2000; WAAS receiver; junction box-NMEA2000; Furuno AIS transponder (FA150) with display and antennas; Furuno satellite compass (SC-50); dedicated interswitch hub for NavNet 3D; (3) ICOM VHF transceiver (M604) w/DSC;(3) Morad VHF antenna (156HD); WeatherStation instrument (200WX); 16 channel NVR high definition (embedded) network series recorder SYS-NCS-16 Classification/Certification: USCG Subchapter K Delivery Date: August 2018
Red and White Fleet
ENHYDRA
Enhydra
Significant Boats of 2018
They will still have the diesels on board, so if they were running a particularly long charter or something like that and the ‘tank’ gets low, it turns back into a hybrid.” Grant added that getting power from the grid makes it more efficient by helping fully utilize the available capacity. “It increases the loading on that [grid] circuit which increases its efficiency. The circuit will either be constantly recharging the batteries or recharging the ship.” Essentially, a hybrid system is about efficiency. Diesel engines are most efficient and have the lowest emissions at 60% to 80% loading, 80% being optimal, according to Grant. So, when engines would be idling or running at a low rpm, that’s the right time to get the needed power from batteries, which should be charged when the engines are running at optimal loading. This type of power-production-
storage-consumption strategy is starting to be used in lots of maritime applications, said Grant. “Cruise ships are stepping up and saying they want to put massive systems on board, partially to go into environmentally sensitive areas like Norwegian fjords or into the Arctic or Antarctic. Or to be more fuel efficient. From what we’ve seen, all of the cruise ships are heading into that direction, using similar hybrid systems.” “For at least a while, our boatyard has more experience with this electric hybrid type system than any other boatyard in the country,” said Matt Mullet, All American’s president. “All American is working to stay at the forefront of the decarbonization movement in the maritime industry, and the lithium-ion hybrid electric propulsion system on the Enhydra is a step in the right direction.”
www.workboat.com • JANUARY 2019 • WorkBoat Significant BoatS
