1.ALL WORK SHALL BE PERFORMED IN COMPLIANCE WITH ALL FEDERAL, STATE AND LOCAL CODES
2.FIRMLY ANCHOR AND BRACE ALL PARTITIONS AS REQUIRED BY CODE.
3. SEE DETAILS FOR CONCEALED BACKING TO BE INSTALLED AT WALL-MOUNTED ITEMS.
4.STAGGER JOINTS OF GYPSUM BOARD AT OPPOSING SIDES OF PARTITIONS.
5. INSTALL DOOR OPENINGS A MINIMUM OF 4" FROM ADJACENT PERPENDICULAR WALLS, UNLESS OTHERWISE NOTED.
6.ALL GLAZING SHALL CONFORM WITH ALL FEDERAL AND LOCAL GLAZING CODES AND ORDINANCES.
7.PROVIDE ALL DOORS COMPLETE WITH ALL HARDWARE FITTINGS AND ACCESSORIES AS REQUIRED FOR SPECIFIC INSTALLATION. ALL DOORS DESIGNATED AS FIRE RATED SHALL BE LABELED AS REQUIRED BY CODE. PROVIDE APPROPRIATE FIRE RATED FRAME SIZED TO SPECIFIC FIRE RATED PARTITION.
8.FURNISH PROPER HARDWARE FOR ALL OPENINGS, WHETHER LISTED OR NOT NOTED. INSTALL HARDWARE ACCORDING TO THE STANDARDS OF THE SPECIFIC MANUFACTURERS USED. REFER TO HARDWARE SCHEDULE FOR DOOR HARDWARE GROUPS.
9.REFER TO DETAILS FOR DOOR HARDWARE AND ACCESSORY MOUNTING INFORMATION.ALL DOORS TO HAVE 1/8" CLEARANCE ABOVE THE FINISHED FLOOR OR THRESHOLD.
10.PROVIDE AND INSTALL A MINIMUM OF TWO 2A10BC CLASSIFICATION FIRE EXTINGUISHERS. VERIFY EXACT LOCATION AND QUANTITY WITH FIRE MARSHAL.
11.ELECTRICAL PANELS SHALL BE INSTALLED WHERE LOCATED AS SHOWN ON THE PLANS. NO OTHER LOCATION SHALL BE PERMITTED WITHOUT THE APPROVAL OF THE ARCHITECT.
12.ALL HARDWARE SHALL COMPLY WITH ALL APPLICABLE BUILDING CODE AND ACCESSIBILITY REQUIREMENTS.
13.CHECK ALL DIMENSIONS AND FIELD VERIFY ALL EXISTING CONDITION
2022 California Building Codes
International Code Council (ICC) Americans With Disabilities Act (ADA)
CODE ANALYSIS
Type II, Fully Automatic Fire-Sprinkler System
1st Floor:
Group A: Assembly, Group B: Business. Group M: Mercantile 2nd Floor: Group B: Business Square footage: 10,917 sq feet
1st Floor: 106 2nd Floor: 31
PLUMBING CALCULATIONS
1st Floor - Occupancy: 106
Water Closets:
Male: 2 (1 ADA ACCESSIBLE)
Female: 2 (1 ADA ACCESSIBLE)
Lavatories
Male: 2
Female: 2
Drinking fountains 1
2nd Floor - Occupancy: 31
Water Closets:
Male: 1 (1 ADA ACCESSIBLE)
Female: 1 (1 ADA ACCESSIBLE)
Lavatories Male: 1
PROJECT DIRECTORY Interior Designer:______________________
The custom built bench accommodates for a wide range of of people.
Seat minimum height and angled seat & backrest allow for comfort use.
The bench also serves as a planter, with enough space to hold large plants and enough room below to fit a sub-irrigation tank system, the planter can re-use water back into the plan itself.
At least 50% of the shelving height & reach is within ADA limits, allowing for a universal usage that encompass many different abilities.
20” depth shelving, limits too far reach that would be uncomfortable for someone in a wheelchair performing side or forward reach.
