WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 1.5
Subject Exhaust gas/Charge air system
Issue date June '00
Internal Exhaust gas and Charge Air System Vee-engine
System components 01 Charge Air cooler HT section 02 Charge Air cooler LT section 03
Turbocharger
04 05 06 07
Compressor cleaning device Air filter and silencer Transition pipe Turbine cleaning device (HFO and DMC only) Flexible connection exhaust Transition piece exhaust Water injector Flexible connection air inlet
08 09 10 11
Pipe connections 501 Exhaust gas outlet 502 Cleaning water to turbine (HFO and DMC only) 503 Cleaning water from turbine (HFO and DMC only) 601 Air inlet to turbocharger
86
