WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 1.2
Subject Lub. oil. system
Issue date June '00
Internal lubricating oil system In-line and V-engine, wet sump
Engine pipe connections
Dimensions L-engine V-engine Ø 22 x 2 22 x Ø2 2 x DN 150 4 x DN 150 DN 100 DN 125 DN 80 DN 80 DN 80 DN 80 DN 80 DN100 DN 80 DN 100 Ø8X1 Ø8X1
153 Leak fuel, lubricating oil and water 202 Lubricating oil outlet 203 Luboil to engine driven pump 209 Luboil to external filter 210 Luboil from external filter 233 Lubricating oil from stand-by pump 701 Crankcase air breather 710 Discharge dirty condensating oil System components: 01 Main luboil pump 02 Non-return valve 03 Pressure control valve 04 Lub oil cooler 05 Thermostatic valve 06 Main luboil filter 07 Sample valve
08 09 10 12 13 14
Centrifugal filter Prelubrication pump Wet sump Turbocharger Strainer Lubricating oil scavenging pump
67
