WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 1.0
Subject Main data
Issue date June '00
Dimensions Engine Line-engine: In-line engine, wet and dry sump, turbocharger at free end
Engine type 6L26 8L26 9L26
A[mm] 4465 5245 5635
B[mm] 4325 5110 5500
C[mm] 1950 2730 3120
Lw[mm] 435 450 445
Ld[mm] 445 460 455
Mx[mm] 1060 1460 1670
My[mm] 75 65 60
In-line engine, wet and dry sump, turbocharger at driving end
Engine type A[mm] 6L26 4492 8L26 5272 9L26 5662 M = centre of gravity.
B[mm] 3875 4660 5050
C[mm] 1950 2730 3120
Lw[mm] 435 450 445
Ld[mm] 445 460 455
Mx[mm] 875 1270 1480
My[mm] 75 65 60
40
