WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 1.0
Subject Main data
Issue date June '00
Weight of engine parts Note: All values are stated in kg. Engine type Cylinder block Cylinder head Lubrication unit Oil sump from/to Crankshaft Flywheel Oil cooler insert ( high capacity ) Turbo charger (0-vers.) A-version Charge air cooler insert Fuel pump Engine foot Exhaust pipes Multiduct Camshaft (1) Pump cover Engine dry sump [t] Engine wet sump [t] Parts Connecting rod Piston + pin Cylinder liner Piston+conrod+liner ass. Crankshaft gearwheel Intermediate gearwheel assembly
6L26 6500 280 850 560 2100 215 40 45 525 335 470 23.6 76 600 44 770 990 18,2 18,5
8L26 8000 280 880
9L26 9200 280 880
12V26 10500 280 1050
3000 210 45 60 525 775 570 23.6 76 800 44 990 990 22 22,5
3200 210 45 60 850 775 570 23.6 76 900 44 1100 990 24,5 25
2300 325 2x55 2x55 525 (2x) 775 680 23.6 76 1200 44 770 995 30 30,5
Weights 83 70 125 288 120 125 ( 40+85 )
16V26 13500 280 1050
18V26 15500 280 1050 800 3330 3500 325 325 2x60 2x60 2x80 2x80 525 2X) 850 2X) 775 775 725 725 23.6 23.6 76 76 1600 1800 44 44 990 1100 995 995 36,5 40 37 40,5
Parts Camshaft gearwheel Cooling water pump Air starter motor Camshaft section Vibration damper Extension piece for vibration damper
Weight 85 47 30 51/32(A) 640 125
