WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 2.5
Subject Engine block/Cylinder liner
Issue date June '00
Guideline for laser line-bore measurements Required measuring equipment Laser transmitter (for example transmitter : Fixtur Digilaser FL11 or Damalini Easy Laser D75)+ special designed bracket (not shown)
Laser detector (for example Digilaser D11 or Easy Laser D5) +. Machine Support line-bore bracket
Display box for signal read out :consisting of laser signal convertor + cables (for example Digilaser display box incl. Adcom or Easy Laser display box).
Laser transmitter for flatness check (for example Digilaser FL100 or Easy Laser D22 ).
170
