WORKSHOP MANUAL W26 Wärtsilä NSD Nederland B.V. Engine type W26
Chapter 1.7
Subject WECS 2000
Issue date June '00
ID-Setting of the smu Tool needed SMU ID Transceiver 8203ZT222 • Remove the connector pins 31/32 on the SMU board • Connect the program module to connector pins 65-68. The display on the module will first display an ‘L’. After a few seconds the current SMU-ID number will be displayed. • You can now select the desired ID-number by pressing the ↑ or the ↓ button on the programming module • When the required ID-number is displayed, press the ENTER button. While transmitting the new ID-number, the display will show an ‘L’. If an error occurs, the display will show an ‘E’. • Disconnect the programming module and reinstall the connector to pins 31/32 • Press the RESET button on the DCU.
The SMU - identification number has now been set.
SMU Supporting plate
35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
122
