Servicing and inspection
10.7.7
Servicing the axles
NOTE Risk of technical damage. ►► Service the transmission and the axles according to the inspection intervals specified in this operating manual.
Fig. 113 Axle
a b
Note Checking / filling and draining screws can be found in the same place on the front and rear axles.
Checking the axle oil level Note The complete axle shares a common oil supply. You can check the oil level on the differential housing.
1. Stop the loader on a horizontal surface and set the parking brake. 2. Lower the lift frame as far as it will go. 3. Turn off the engine. 4. Remove the hexagonal screw Item a (Fig. 113). 5. The transmission oil must be at or below the bottom edge of the filler neck. 6. If necessary, top up the transmission oil. 7. Screw the hexagonal screw back in Item a (Fig. 113).
215
