4.15
Pressure pump support VF5
Position the pressure pimp support in a vice fitted with protective jaws. Lock the rotation of the pressure pump drive pulley using two bolts. Undo the pressure pump drive pulley nut. Undo the two bolts for locking the rotation of the pressure pump drive pulley fitted previously.
Remove the pressure pump drive pulley (1 a) using the tools (1b extractor).
76 402102.01
Service manual VF4 VF5
