4.10
Pressure relief sensor
Make sure that the ignition key is it in the OFF position, then disconnect the battery terminal (-). Undo bolts (2 a) and remove the pressure relief sensor (2b).
Position the excess pressure sensor (1 a) in its housing and secure it tightening the bolt(1b) to the recommended torque. Excess pressure sensor Bolt M ... (daNm)
0.9
Connect the electrical connection for the pressure relief sensor. Connect the negative (-) battery terminal.
Service manual VF4 VF5
402102.01 67
