4.8
Fuel filter assembly
Make sure that the ignition key is in the OFF position then, disconnect the battery terminal (-) . Disconnect the rapid connectors from the fuel filter, fuel filter side. Unscrew the fuel filter from the bracket. Raise the fuel filter assembly (3 a) by the required amount and disconnect the electrical connection (3b) from the water presence sensor, then remove. Working at the bench, unscrew the water presence sensor in the fuel filter and remove.
Refit the water sensor in its seat on the fuel filter. Connect the electrical connection to the water presence sensor, then refit the fuel filter assembly in its seat. To screw the filter in its seat of the bracket. Connect the rapid connectors for the fuel pipes, fuel filter side. Connect the negative battery terminal (-).
Service manual VF4 VF5
402102.01 65
