4.1.3
Camshaft housing.
Position the camshaft housing in the vice using the tool (support). Tighten the engine oil lubrication duct plugs. Place the camshaft gears in their housings. Place the camshaft gears in their housings and secure them without tightening the bolts. Fit the camshaft timing tools (template) Check that the tools are correctly fitted in the housings in the camshaft.
Tighten the camshaft gear fixing bolts to the recommended torque. Camshaft gears Bolt M12
28 402102.01
(da Nm) camshaft side 2.9 ÷ 3.2 + 40°
Service manual VF4 VF5
