Removing the Heatsink and Fan Module 1.
Turn the mainboard over. Locate and remove the five screws (red markers) and fan connector (yellow marker) from the mainboard.
2.
Remove the Heatsink securing bracket as shown.
3.
Remove the Heatsink as shown.
4.
Steady the Mainboard with one hand and remove the Fan Module by lifting straight up.
Chapter 3
75
