4. Grip the mainboard from the front and lift up. NOTE: If any resistance is met while removing the mainboard, ease the computer case outward to clear the obstruction.
5.
Lift the mainboard clear of the chassis.
Removing the I/O Board
74
1.
Locate and remove the two screws as shown.
2.
Lift the board toward the front of the computer to clear the port and remove from the chassis.
Chapter 3
