3.
Locate Dummy Tray 2 and press the release button as shown.
4.
Remove Dummy Tray 2.
Removing the Switch Cover CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is recommended that only fingers are used to remove the Switch Cover.
66
1.
Turn the computer over. Locate and remove the two securing screws as shown.
2.
Open the LCM module fully to expose the Switch Cover.
3.
Grip the Switch Cover as shown and pull upward to remove.
Chapter 3
