Advanced The Advanced screen displays advanced settings in BIOS.
Phoenix - Award WorkstationBIOS CMOS Setup Utility Advanced Serial Port
[Auto]
Infrared Port (FIR)
Help Item
[Auto]
Parallel Port
[Auto]
Mode
[ECP]
Menu Level
X
XASF Configuration Minimum Watchdog Timeout
[ ]
BIOS Boot Timeout
[ ]
OS Boot Timeout
[ ]
Power-on wait Time
[ ]
KLIJ :Move Enter: Select +/-/PU/PD :Value F10: Save and Exit ESC:Exit F1: General Help
F5: Previous Values
F7: Optimized Defaults
The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings.
Parameter
Option
Serial port
Displays the setting of the serial port
Auto or Disabled
Infrared port
Displays the setting of the infrared port
Auto or Disabled
Parallel port
Displays the setting of the parallel port
Auto or Disabled
Mode
Displays the mode of the parallel port if enabled
ECP/SPP/EPP
ASF Configuration
Access the ASF Submenu for the following features:
Enter a figure in minutes
q q q q
48
Description
Minimum Watchdog Timeout BIOS Boot Timeout OS Boot Timeout Power-on wait Time
q q q q
Minimum Watchdog Timeout — BIOS Boot Timeout — OS Boot Timeout — Power-on wait Time —
Chapter 2
