2
Memory compartment
Houses the computer’s main memory.
3
Battery lock
Locks the battery in position.
4
Battery release latch
Releases the battery for removal.
5
Battery bay
Houses the computer’s battery pack.
6
Hard disk bay
Houses the computer’s hard disk (secured with screws)
7
Sub woofer
Emits low frequency sound output.
Indicators The computer has several easy-to-read status indicators.
The front panel indicators are visible even when the computer cover is closed up.
Icon
12
Function
Description
Standby
Indicates the computer’s standby status.
HDD
Indicates when the hard disc or optical drive is active.
Cap lock
Lights when Cap Lock is activated
Num lock
Lights when Num Lock is activated.
Power
Lights up when the computer is on.
Chapter 1
