Icon
Item
Description
5
Ventilation slots
Enable the computer to stay cool, even after prolonged use.
6
S-video/TV-out (NTSC/PAL) port
Connects to a television or display device with S-video input.
7
External display (VGA) port
Connects to a display device (e.g., external monitor, LCD projector).
8
DVI-D port
Supports digital video connections.
9
Ethernet (RJ-45)
Connects to an Ethernet 10/100/1000based network (for selected models).
10
Parallel port
Connects to a printer.
11
Serial port
Connects to a serial device.
Base view
# 1
Item Ventilation slots and cooling fan
Description Enable the computer to stay cool, even after prolonged use. Note: Do not cover or obstruct the opening of the fan.
Chapter 1
11
