3
3 USB 2.0 ports
Connect to USB 2.0 devices (e.g., USB mouse, USB camera).
4
4-pin IEEE 1394 port
Connects to IEEE 1394 devices.
5
PC Card slot eject button
Ejects the PC Card from the slot.
6
PC Card slot
Accepts one Type II PC Card.
7
Express Card/54 slot
Accepts and ExpressCard/34 module Note: ExpressCards are third generation of PC cards, hot-swapable and smaller than previous PC Cards. Designed for both desktop and mobile use, ExpressCards use either USB 2.0 or a single lane PCI Express technology that provides 500 Mbytes/sec total throughput. Formerly code named "NEWCARD," ExpressCards are 5 mm thick like Type II PC Cards, but do not use the same 86x54 mm footprint. ExpressCards come in 75x54 mm and 75x34 mm sizes. Express Card/54 slot means this notebook accepts 75x54mm ExpressCards.
Rear view
#
10
Icon
Item
Description
1
DC-in jack
Connects to an AC adapter.
2
TV-in port
Accepts input signals from analog/digital TV-tuner devices (for selected models).
3
AV-in port
Accepts input signals from audio/video (AV) devices (manufacturing option).
4
Kensington lock slot
Connects to a Kensington-compatible computer security lock.
Chapter 1
