10/11 12
Easy-launch buttons
Buttons for launching frequently used programs.
Power button
Turns the computer on and off.
Closed Front View
#
8
Icon
Item
Description
1
Speaker
Left and right speakers deliver stereo audio output.
2
Infrared port/CIR receiver
Interfaces with infrared devices (e.g, infrared printer and IR-aware computer)/ Receives signals from a remote control.
3
Line-in jack
Accepts audio line-in devices (e.g., audio CD player, stereo walkman).
4
Microphone-in jack
Accepts input from external microphones.
5
Headphones/speaker/ line-out jack with S/ PDIF support
Connects to audio line-out devices (e.g., speakers, headphones).
6
Power indicator
Indicates the computer’s power status.
7
Battery indicator
Indicates the computer’s battery status.
8
Bluetooth® communication button/ indicator
Enables/disables the Bluetooth® function. Indicates the status of Bluetooth communication.
9
Wireless communication button/ indicator
Enables/disables the wireless function. Indicates the status of wireless LAN communication.
Chapter 1
