Connector Descriptions CN1 RJ11 Connector (4-PIN) Signal name
I/O
PIN No.
Signal name
I/O
1
PIN No.
MDMRNG_DOCK
I/O
3
MDMRNG_DOCK
I/O
2
MDMTIP_DOCK
I/O
4
MDMTIP_DOCK
I/O
CN2 LCD I/F Connector (40-PIN) PIN No.
I/O
PIN No.
+V5S
-
21
LVDS_TXDL2+
I
2
INV_PWM_3
I
22
GND
-
3
+V5S
-
23
LVDS_TXDL2-
I
4
GND
-
24
LVDS_TXDL1+
I
5
BKLTEN
I
25
GND
-
6
LVDS_TXCU+
I
26
LVDS_TXDL1-
I
7
GND
-
27
LVDS_TXDL0+
I
8
LVDS_TXCU-
I
28
GND
-
9
LVDS_TXDU2+
I
29
LVDS_TXDL0-
I
10
GND
-
30
LCM_DDCPDATA
I/O
11
LVDS_TXDU2-
I
31
GND
-
1
Signal name
Signal name
I/O
12
LVDS_TXDU1+
I
32
NC
-
13
GND
-
33
LCM_DDCPCLK
I/O
14
LVDS_TXDU1-
I
34
+V3S_DSC
-
15
LVDS_TXDU0+
I
35
GND
-
16
GND
-
36
+V3S
-
17
LVDS_TXDU0-
I
37
USB_PN6
I/O
18
LVDS_TXCL+
I
38
+V3S_LCM
-
19
GND
-
39
USB_PP6
I/O
20
LVDS_TXCL-
I
40
+V3S_LCM
-
