Bottom View
116
1
CN1004
MB & I/O board CNTR
15
Jack1003
Line-in jack
2
JACK1001
RJ-45
16
D1029
IR receiver
3
CN1001
Serial port
17
CN1016
PCI-E socket
4
CN1003
DVI port
18
CN6032
New card socket
5
CN1002
VGA port
19
CN1009
CPU socket
6
JACK1000
DC IN jack
20
CN1014
USB
7
CN1000
FAN cable CNTR
21
CN1010
USB
8
CN1005
Docking CNTR
22
CN1007
1394
9
CN1018
Second battery CNTR
23
U6002
North bridge
10
CN1008
ODD CNTR
24
U6004
South bridge
11
CN1015
Battery CNTR
25
CN1012
DIMM socket
12
CN1017
HDD CNTR
26
CN1013
DIMM socket
13
Jack710
Headphone jack
27
CN1006
W/LAN card CNTR
14
Jack1002
MIC jack
