Jumper and Connector Locations Top View
1
CN2
LCM Cable CNTR
2
CN3
MDC CNTR
3
CN1
MDC Cable CNTR
4
CN5
Hot key board CNTR
5
CN4
Key board FFC CNTR
6
CN6
Fine track FFC CNTR
7
CN7
Smart card FFC CNTR
8
CN8
Touch pad FFC CNTR
9
CN9
MIC cable CNTR
10
CN12
3G card CNTR
11
CN14
Blue tooth cable CNTR
12
CN11
Speaker cable CNTR
13
CN13
Speaker cable CNTR
14
CN10
5in1 card reader CNTR
