Replacing the Wireless Card 1. Ensure the card is positioned label upwards as shown and push into the connector. NOTE: The card remains at an angle until the screws are inserted.
2.
Secure the card in position using the two screws provided.
3.
Reconnect the three Antenna Cables as shown, pushing down firmly to connect the cables.
Cable Color
Connector Number
No Tape
1
White Tape
2
Red Tape
3
