Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the distette drive in module bay, the onboard hard disk drive and the CD-ROM in module bay and onboard LAN device.
PhoenixBIOS Setup Utility Info.
Main
Advanced
Boot
Security
Item Specific Help
Boot priority order: 1: USB KEY: 2: USB FDC: 3: USB HDD: 4: IDE 0: ST9100824ASIDE S 6: PCI SCSI 7: PCI LAN: MBA v8.2.6 Slot 0300
F1 Help
↑ ↓
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub-Menu
F10 Save and Exit
Parameter Boot priority order
Keys used to view or configure devices: Up and Down arrows select a device. <+> and <-> moves the device up or down. <f> and <r> specifies the device fixed or removable. <x> exclude or include the device to boot. <Shift + 1> enables or disables a device. <1- 4 > Loads default boot sequence.
Select Item
←→
Esc Exit
Exit
Description Keys used to view or configure devices: Up and Down arrows select a device. <+> and <-> movew the device up or down. <f> and <r> specifies the device fixed or removable. > <x> exclude or include the device to boot. <Shift +1> enables or disables a device. <1-4> Loads default boot sequence.
.
Chapter 2
60
