Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel® Core Duo processor T2300/T2300E/T2400/T2500/T2600, Intel® Core Solo processor T1300 Intel® CoreTM 2 Duo processor T5500/T5600 (2MB L2 cache, 1.66/1.83 GHz, 667 MHz FSB) Intel® CoreTM 2 Duo processor T7200/T7400/T7600(4MB L2 cache, 2/2.16/ 2.33 GHz, 667 MHz FSB)
CPU package
Micro-FCPGA /Micro-FCBGA
CPU core voltage
Depend on DVI
CPU I/O voltage
1.05V typical
L2 cache
2MB
CPU Fan True Value Table Stage
DTS(degree C)
Local
Fan Speed(rpm)
Acoustic Level(dBA)
1
2910
50
56
29
2
3320
60
60
32
3
3720
70
65
25
4
4170
82
70
38
5
4430
93
77
40
System Board Major Chips Item
Controller
System core logic
Intel 945PM + ICH7M
Super I/O controller
ICH7M LPC interface
Audio controller
Azalia Audio Controller ALC883DD
Video controller
Nvidia G72MV/G71M/G73M
Hard disk drive controller
ICH7M
Keyboard controller
KB3910SF
DVI controller
Nvidia G72MV/G71M/G73M
®
PCMCIA controller
PCI 7412
DDR-soDIMM controller
945PM
BIOS Item
42
Specification
BIOS vendor
Phoenix
BIOS Version
Phoenix First BIOS
BIOS ROM type
1MB CMOS Boot Block Flash Memory
BIOS ROM size
1MB
BIOS package
40 pin TSOP
BIOS password control
Set by setup manual
Chapter 1
