Exploded Diagram 3
4
7
:
5
9
6
8
21
2
22 38
23 26 24
27
28
25
29 2:
32
31
33 34
35
37
36
TDBMF!!
Item
103
Description
Item
1/411
Description
1
LCD bezel
2
LCD panel
3
LCD module
4
CAS camera upper case
5
Camera hinge
6
Camera cap
7
CCD PCB
8
Camera lower case
9
Left LCD bracket
10
Right LCD bracket
11
LCD cable
12
Middle cover
13
Upper case
14
Keyboard
15
Launch board
16
LED bracket
17
Touch pad
18
Touchpad bracket
19
Battery
20
Lower case
21
Mainboard
22
ODD
