Main This menu provides you the information of the system.
Insyde Software SCU Main Advanced Date and Time ԩ Quiet Boot ԩ LCD Auto DIM ˲ʳ Network Boot ˲ʳ ʳ F12 Boot Menu ԩ D2D Recoveryʳ
May 20, 2003 Security
Boot
5:40:09 Exit
AM
Enable or disable the F12 key for Boot Menu during POST <Space> for select
Parameter
48
Description
Date and Time
The hours are displayed with 24 hours format. The values set in these two fields take effect immediately.
Quiet Boot
Customer Logo display will be shown during POST when it is selected.
LCD Auto DIM
Enabled: LCD brightness will automatically lower to save more power when AC is not present. Disabled: LCD brightness will NOT automatically lower to save more power when AC is not present.
Network Boot
When this is selected, Boot from LAN feature is enabled. When this is not selected, Boot from LAN feature is then disabled
F12 Boot Menu
When this is selected, users can modify device boot priority by pressing <F12> key during POST. When this is not selected, device boot priority will not be adjustable during POST
D2D Recovery
Allow user to enable/disable the Disk-to-Disk recovery Enabled: Enable D2D Recovery/eRecovery Disabled: Disable D2D Recovery/eRecovery Help note: Enable Acer disc-to-disc system recovery via Alt+F10 key during POST. Options: Enable or Disable
Chapter 2
