Bottom View
# #
14
Item
Description Item
Description
1
Memory compartment
Houses the computer's main memory.
2
Hard disk bay
Houses the computer's hard disk (secured by a screw).
3
Battery release latch
Unlatches the battery to remove the battery pack.
4
Battery bay
Houses the computer's battery pack.
5
Cooling fan
Helps keep the computer cool. NOTE: Do not cover or obstruct the opening of the fan.
6
AcerMedia Bay (for TravelMate 4650 Series)
Houses an optical drive module or a second battery pack.
7
AcerMedia Bay release latch (for TravelMate 4650 Series)
Unlatches the AcerMedia module for removal of module.
