Hardware Specifications and Configurations Processor Item
Specification
CPU type
®
Intel
Intel® ®
Intel
Pentium
®
M YonahProcessor dual core at 1.66~2.33 GHz or higher
Pentium
®
M Yonah Processor single core at 1.66~1.83 GHz higher
®
M Yonah Processosr 430/420/410
Celeron
CPU package
uFCPGA
CPU core voltage
Depend on DVI
CPU I/O voltage
1.2V
System Board Major Chips Item System core logic
Controller ®
Intel 945GM/ICH7M Intel® 945PM/ICH7M
Super I/O controller
SIO 1000, LPC interface
Audio controller
Azalia Audio Controller ALC883
Video controller
ATI M56P/54P/52P UMA
Hard disk drive controller
ICH7M
Keyboard controller
NS PC97541V
IrDA controller
SMSC SIO 1000
DVI controller
CH7307
PCMCIA/ card reader / 1394 controller
TI PCI7412
DDR-soDIMM controller
945PM/945GM
BIOS Item
Specification
BIOS vendor
Phoenix
BIOS Version
Phoenix First BIOS
BIOS ROM type
Flash ROM
BIOS ROM size
512KB
BIOS package
32 lead of TSSOP
BIOS password control
Set by setup manual
Item Cache controller
38
Specification Built-in CPU
Cache size
2 MB
1st level cache control
Always enabled
2nd level cache control
Always enabled
Cache scheme control
Always enabled
Chapter 1
