Electrical System – 5000 Parameters Valid from serial number 723984-Order number 222995-040
T-code 677, 678, 679 Date 2005-02-02
Parameter #16 to 19 configurable optional functions Parameter no. #16, #17, #18 & #19 can be adjusted to activate up to a maximum of 4 pre-programmed functions and configure these to suit optional equipment or customisation of the truck. See “Table 2:List of configurable optional functions” on page 39. These are thus called the configurable optional functions. • Each parameter can be programmed to cover a specific optional function. • Each optional function can have up to 4 independent variables associated with it. • Each independent variable has a value you can change to configure the function. Parameter no. (range 16-19) Independent variable: #0 is the option designation
16 - 0 - 1
Independent variable value (range 0-63) 0= no option has been activated for this parameter 1 to 63 = Pre-programmed option number. See separate table.)
SETTING THE OPTIONAL FUNCTION
Independent variable: #1, #2, #3 & #4 contain the optional function valu
16 - 1- 1
Independent variable value (the range depends on the function referred The value depends on the option and independent variable selected. See separate table CONFIGURING THE OPTIONAL FUNCTION
Fig. 1Summary – option parameter
Changing configurable optional functions In order to activate a configurable optional function, it must first be assigned a parameter from #16 to #19. This is done by changing independent variable #0 to the pre-programmed option number. Once this has been done, the independent variable for the option must be configured. This is done by changing the values for independent variables #1, #2, #3 and #4. • Ensure the truck is in parameter mode.
The parameter symbol is lit. © TIEE SARL
Service Manual 7PM18, 7PM20, 7PML20Approved by: L-G Andersson
13- 37
