Electrical System – 5000 Parameters Valid from serial number 723984-Order number 222995-040
T-code 677, 678, 679 Date 2005-02-02
Parameter 14 Specifies the speed you will have when you reach the first speed sensor.
Parameter 15 - Non-configurable option See “Option parameters” on page 35,
Parameter 16 - Configurable option #1 See “Option parameters” on page 35,
Parameter 17 - Configurable option #2 See “Option parameters” on page 35,
Parameter 18 - Configurable option #3 See “Option parameters” on page 35,
Parameter 19 - Configurable option #4 See “Option parameters” on page 35,
Option parameters WARNING ! Do not try to change these parameter unless you have specific knowledge of the truck options or truck modifications. This service manual only covers the truck’s standard equipment. Specially modified trucks may require you to have access to particular service information. Incorrect adjustment of option parameters may result in incorrect function.
General Parameters #15 to #19 have been reserved in the truck control system for extra options and/or specific product modifications. These parameters are normally configured by the manufacturer on modification or customisation of the truck. It is recommended that the parameter settings be loaded up from the truck when carrying out any modification. If, for example, the main electronic card [A2] must be replaced, the original parameter settings can then be simply transferred to the new card, which ensures that all the special options function correctly.
Parameter #15 Non-configurable options Up to 16 so-called sub-parameters are stored under parameter #15. Their status is either ON or OFF and they do not require any other adjustments. They are therefore called non-configurable options.
© TIEE SARL
Service Manual 7PM18, 7PM20, 7PML20Approved by: L-G Andersson
13- 35
