Electrical System – 5000 Parameters T-code 677, 678, 679 Date 2005-02-02
Parameter
Description
Unit
16
Configurable option #1
See “Option parameters” on page 35,
17
Configurable option #2
18
Configurable option #3
19
Configurable option #4
20
Hour meter option
1
5
1
2
Select hour meter.
21
Battery size
1
20
1
95
Selection of battery size.
22
Inductive sensor
0
1
1
1
0: Mechanical switch 1: Inductive sensor
25
Service interval
0
2000
50
100
Option for setting service timer
28
Lift button selection
1
3
1
1
Button selection
39
Password
1
12
1
1
States which level of authorization the driver has for the parameters. Odd values specify open driver parameters, even values specify that driver parameters must be opened using the CAN key
1h
Min .
Valid from serial number 723984-Order number 222995-040
Max .
Step
Std .
Description
13.6.4 Parameter description Parameter 10 NOTE! The functionality of parameter #10 is set aside if the value of parameter #39 is set to 5,6,7 or 8. The PIN codes are managed using the socalled expanded keypad. See section Expanded keypad - General on page 47 for more detailed information.
Ten drivers can have their own PIN code to gain access to the truck. Each driver can set all driver parameters individually. On delivery the PIN code is set to 1 and this only applies for driver no. 1. Code 0 is not accepted as a solitary code. When you wish to start the truck enter your code and press the green button numbered 1. When you want to switch off the truck, press the red button numbered 0. When the CAN key is connected, you can start the truck by simply pressing the green button numbered 1. Switch off by pressing the red button numbered 0. 13- 34
© TIEE SARL
Service Manual 7PM18, 7PM20, 7PML20
Approved by: L-G Andersson
