Electrical System – 5000 Parameters Valid from serial number 723984-Order number 222995-040
T-code 677, 678, 679 Date 2005-02-02
13.6.3 Service parameters • Connect the CAN key to X41.
A
• Press and hold S18 while turning S17 to “ON” position. • Press and hold S18 until P = parameters is displayed. • You have now selected P = parameters and the symbol “C” is lit as an indication of what is now shown in the display.
E
D
C
B
• Press L1 up or down and scroll to the parameter you want to change or view. • Press S18 once to access the parameter. • Press L1 up or down to specify the parameter value. • Press S18 once to confirm the change. • Turn S17 to the off position. You have now changed the parameter and the new setting will come into force the next time you start the machine. NOTE: Truck handling When you change specific truck parameters, the truck’s driving characteristics are also changed. Do not change any parameters unless you really know what you are doing.
Parameter
Description
10
Min .
Max .
Step
Std .
Description
PIN-code
0
9999
1
1
Facility for specifying up to 10 PIN codes (10 different drivers).
14
Crawling speed
-10
10
1
0
The amount of power the monitor should emit when you reach the first speed sensor can be specified here. -10: low speed for the first speed sensor. 10: high speed for the first speed sensor
15
Non-configurable option 0 to 9
© TIEE SARL
Unit
See “Option parameters” on page 35,
Service Manual 7PM18, 7PM20, 7PML20Approved by: L-G Andersson
13- 33
