Electrical System – 5000 Error codes Valid from serial number 723984-Order number 222995-040
© TIEE SARL
T-code 677, 678, 679 Date 2005-02-02
Code
C90 (Option)
Description
Extra I/0 (0) CAN communication error
Possible error cause
Data from extra I/0 box /(0) not being received by [A2]/ Check the CAN-bus cable and the connections. [A2] Restart the truck.
Code
C91 (Option)
Description
Extra I/0 (1) CAN communication error
Possible error cause
Data from extra I/0 box /(1) not being received by [A2]/ Check the CAN-bus cable and the connections. [A2] Restart the truck.
Code
C92 (Option)
Description
Configuration error Extra I/0 (0)
Possible error cause
Incorrect setting of options in the extra I/0 box (0) Check the outputs’ allocation on the I/0 expansion box (0)
Code
C93 (Option)
Description
Configuration error Extra I/0 (1)
Possible error cause
Incorrect setting of options in the extra I/0 box (1) Check the outputs’ allocation on the I/0 expansion box (1)
Service Manual 7PM18, 7PM20, 7PML20Approved by: L-G Andersson
13- 23
