Electrical System – 5000 Error codes Valid from serial number 723984-Order number 222995-040
T-code 677, 678, 679 Date 2005-02-02
13.5 Error codes • Press and hold S18 while turning S17 to “ON” position. • Press and hold S18 until E = error codes is displayed. • When E is selected, the “E” symbol will light up as an indication of what is shown in the display. • The 50 most recent error codes are stored. The latest error is displayed first. The display shows the error code first, followed by the time when the error occurred. • The error codes are divided into two groups, C = caution and E = error. • C codes are not stored. They are only cautions and remain lit in the display as long as the fault remains. • If there is only one error registered in the memory, the other empty entry lines appear as follows: Error: E - - - and time: - - - - .
© TIEE SARL
Code
C3
Description
TLS: Shock sensors registered values outside the limits
Possible error cause
A shock sensor has reported values that exceed the truck’s tolerance values. Driving may be too hard Check that the shock sensor’s limit values are correctly set. Check that the shock sensor is correctly positioned./The brake engages and stops the truck. The TLS reset command activates the truck
Code
C4
Description
TLS: Use of the truck has been blocked
Possible error cause
Truck use can be “blocked” by a TLS command. / The truck cannot be used until a new TLS command cancels the blocking of the truck
Service Manual 7PM18, 7PM20, 7PML20Approved by: L-G Andersson
13- 17
