Functions of and How to Use Adjustment Mode 2.4 Procedure of Winch Drum Position Setting [NOTICE] The center of gravity of winch drum can be changed by adjusting the winch drum position. The calculation is performed according to the winch drum position setting by this function. 1. Select the main menu [• Reg. Capac. ] in the adjustment mode, and press the register key to select the menu. 2. Press the scroll-up or scroll-down key to display [: Winch drum PSN], and then press the register key to select the menu. 3. The currently registered jib capacity condition is indicated on the moment display. Using the scroll-up or scroll-down key, adjust it to the desired condition. Display example: [Winch drum = FR ] Press the scroll-up key. [Winch drum : F ] Press the scroll-up key. [Winch drum : R] In the above examples, “F” means the condition with single winch mounted at the front. “R” means the condition with single winch mounted at the rear. “FR” means the condition with double winches mounted at the front and rear. The conditions with “ = ” is the currently registered condition. 4. When the desired condition is displayed, press the register key for confirmation. When the setting has been completed, “:” in the winch drum condition display changes to “ = ”. Display example: [Winch drum : F ] Press the register key. [Winch drum = F ] 5. Press the display alteration key to exit the menu.
