Functions of and How to Use User Mode (TT-300XL-1) Display Panel 2
3. "on-rubber" state symbol
1. Front jack When the front jack is set, the symbol lights to
When power is supplied (PTO switch is turned
indicate that the front jack is set.
ON), the symbol lights to indicate that the outriggers are not set.
2. Outrigger state symbol
4. Boom position indicator
Indicates the way the outriggers are extended.
Indicates the boom position in 10° increments.
Flashes while an outrigger state is in process of being registered, and lights up when the registration is completed.
22
W301-0311E
