Functions of and How to Use User Mode (TT-300XL-1) [OPERATION]
2. Maintenance Mode: Used to make functional checks of AML. See the “ADJUSTMENT AND MAINTENANCE” section.
Functions of and How to Use User Mode (TT-300XL-1)
3. Adjustment Mode: Used to make detector adjustment. See the “ADJUSTMENT AND MAINTENANCE” section.
Mode Structure The AML device has three modes and AML functions are allotted for these models. POWER ON
Protect switch ON
MAINTENANCE MODE
USER MODE
Protect switch OFF
ADJUSTMENT MODE
POWER ON
IW301-0212E05
1. User Mode: Used to indicate moment ratio or to perform AML pre-opetational inspection (Normally used). In normal use, turn ON the protect switch mounted on the adjustment window on the top of AML. AML will go to the user mode when the power turns on. The abnormality display LED lights when the AML
HALT
ZERO
WDT
PROTECT ON
OFF
MOMENT SHORT
is in abnormal conditions (to indicate that the CPU is faulty).
Protect switch Abnormality display LED Top view
IW301-0132E35
13
W301-0311E
