Bucyrus International, Inc. 59HR ELECTRIC BLAST HOLE DRILL
OPERATOR’S DISPLAY TERMINAL
The Operator’s Display Terminal consists of an active matrix display, keypads and industrial computer (PC). The operator’s Display Terminal displays status information for all PLC controlled machine functions. Some machine setup parameters may be entered using the keypad. Refer to the topic at the end of this section for further operational procedures for the Operator’s Display Terminal.
Operator’s Display Panel
Manual No. 10425
34
August 2006
