BI616959
Bucyrus International, Inc. 59HR ELECTRIC BLAST HOLE DRILL
MACHINE PLACARDS Shown below are samples of various safety decals found on the 59HR Blast Hole Drill. These decals are for the protection of all personnel who have contact with the machine. If the decals on the machine become unreadable, defaced or missing, they should be replaced immediately. Duplicates are available from Bucyrus International, Inc. Parts Sales Department. When ordering the decals use the part numbers indicated.
TO PREVENT BO DILY INJU RY
sgna_59r
Part No. 61349524 7 x 10 Inches ~Red and Black on White. Located inside the operator’s cab, on the wall behind the operator’s console.
sgnb_59r
Part No. 61349574 7 x 10 Inches ~Red and Black on White. Located on the doors of the electrical cabinet in the machinery house.
TO PREVENT IN JURY
sgnc_59r
Part No. B004124-01 7 x 10 Inches ~Red and Black on White. Located on the right side of the machinery house on the doors to the high voltage transformer enclosure, and on the left side of the house, above the main junction box.
Manual No. 10425
sgnd_59r
Part No. C105719-01 10 x 14 Inches ~Red and Black on White. Located on the right side of the machine near the boarding stairs, and at the left-front corner of the machine.
14
August 2006
