RG 170.B
TECHNICAL DATA BLADE REACH (MEASURED OUTSIDE TIRES), ARTICULATED FRAME With machine articulated a full 250 to the right and to the left, add 684 mm for all above dimensions. (*) 3-hole saddle .... tire 13x24 ...... blade12 ft (**) 5-hole saddle .. tire14x24 ....... blade12 ft HYDRAULIC SYSTEM Full hydraulic control, supplied by a "Load Sensing" type gear pump. Closed center circuits. Blade raise cylinders mounted over the saddle. Saddle lock system by a hydraulic cylinder controlled by a solenoid valve activated by a switch located on the side console. Relief and check valves for all controls.
FRONT BLADE Type ................................................ Front mounted Weight ......................................... 2.56 lbs(165 Kg) Dimensions .................................. 2.762 x 953 mm Maximum penetration .................. 6.4 in (165 mm) Machine length with front blade fully retracted ................................ 9.404mm The information given herein is general and should not be constued to serve any specific purpose or application. NEW HOLLAND reserves the right to make changes or improvements to these specifications without notice.
Maximum flow Implements .............................. (51 gpm) 193 l/min Steering / brakes ................................... 37,0 l/min Maximum pressure Implements ......................................... 197 Kg/cm2 Brakes .................................................. 65 Kg/cm2 ACCESSORIES SCARIFIER Parallelogram type, front mounted Weight (5 teeth) ......................... 1428 lbs (648 Kg) Weight (11 teeth) ........................ 1521 lbs (690 Kg) Width ........................................... 46 in (1.168mm) Number of teeth ......................................... 5 ou 11 Tooth spacing 5 teeth .............................................. 9 in (229mm) 11 teeth ........................................ 4.5 in (114 mm) Maximum raise height from the ground ................. ....................................................... 21 in (527mm) Maximum ground penetration ....... 12,5 in (318mm) Overall machine length with scarifier ..................... ................................................. 372 in (9.452 mm) REAR RIPPER Type ........................... parallelogram, rear mounted Weight ........................................................ 617 Kg Number of teeth .................................................. 5 Tooth spacing .............................. 20.8 in (530 mm) Width ........................................... 88 in (2337 mm) Maximum raise height from ground ....................... ................................................... 22.9 in (582 mm) Maximum ground penetration ...... 13.7 in (350 mm) Machine length with rear ripper fully retracted ............................ 377 in (9576 mm)
Read the SAFETY RULES on the preceding pages for machine protection and the safety of employees
24
