SECTION V - TRANSPORTATION
5.2 LIFTING MACHINE
4. Slowly lift and move machine to desired location.
The following procedures are for lifting the machine, as built by your Dealer. These procedures do not take into account modifications made to the machine that affect machine weight or center of gravity. 1. Locate lifting locations at the front and rear of each crawler frame. 2. Attach cables or wire rope with a capacity rating sufficient to lift the machine, at lifting locations.
WARNING Always use proper lifting equipment and devices. Use of improper lifting equipment could allow the load to shift or fall causing severe damage, serious injury or death.
WARNING Do not use counterweight lifting eyes to lift whole machine. Lifting eyes can fall under this load resulting in personal injury. Refer to operators manual for proper way of lifting machine.
CAUTION Place a hardwood or steel block between cables and crawler frame to prevent damage to the tracks from cables during lifting.
3. Bring loose ends of cables together at machine center of gravity and attach to an overhead lifting device with a rated lifting capacity sufficient to lift the machine. TOOLS
(A)
(7 °)
Q'TY
CABLE (A)
Ø25 X 13.6 m
1
CABLE (B)
Ø25 X 13.7 m
1
3.67 m
2
SPREADER BARS (C)
0°
(1
)
1900 mm (6´-3˝)
WEIGHT: 11,900 kg (26,230 lbs) ARM: 2.2 m (7’-3”) SHOE: 600 mm (23,6”) MODEL: E115SR
SIZE
ITEM
NOTE: It may be necessary to place reinforced spreader bars between lifting cables to prevent damage to the machine during lifting.
(B)
(44
°) (44°)
3670 mm (12˝)
3100 mm (10´-2˝)
CENTER OF GRAVITY
(C)
632 mm (24.9˝) NOTE:
148
Lifting machine with wider track shoes will tend to shift the Center of Gravity slightly forward, toward the center of the slewing ring.
586 mm (23˝)
PLACE BLOCK BETWEEN EACH CABLE AND FRAME
F16438gb
WARNING Do not use the counterweight lifting eyes to lift machine.
