Operation Backup warning system The backup warning system consists of a backup alarm A fitted on the inside of the cover over the towing device, and a switch and wiring. The backup alarm generates an acoustic signal when you shift into reverse. The acoustic level is about 103 dB(A) at a distance of 3’ (1 m) and at a frequency of 2800 Hz. WARNING! When backing up with the machine –
Accident risk. ☞ Make sure nobody is within the work area of danger of the machine. ☞ Do not rely exclusively on the backup alarm to alert others.
A
Fig. 43: Backup warning system
Differential lock
IMPORTANT! A differential lock distributes traction evenly to the front and rear wheels. Both the front and rear axles of the machine are fitted with self-locking differentials. The lock value is 45% for each axle. The differential is locked automatically and cannot be turned on or off by the operator.
