Controls Table 25: Configuration Screens Item
Access/Description Travel Speed Limit Configuration Screen (Option) This screen displays only on machines equipped with the speed limit option. Press and release interface button (Z, Fig. 7) to choose between H-L (high/low) or speed limit travel drive modes. See “Travel Speed Range Selection” on page 62 for more information about the travel speed limit option. Vehicle speed limit configuration changes are saved when exiting this screen. To exit this screen, press and hold interface button for 5 seconds. Control Joystick ISO/D-H Pattern Selection Screen (Option) This screen displays only on machines equipped with the D-H control pattern option. Press and release interface button (Z, Fig. 7) to choose between ISO or D-H joystick control options. See “Control Joysticks” on page 53 for more information about the ISO and D-H control options. Control joystick pattern configuration changes are saved when exiting this screen. To exit this screen, press and hold interface button for 5 seconds. Coolant Temperature °F/°C Units Selection Screen Press and release interface button (Z, Fig. 7) to choose between coolant temperature display options (°F/°C). Coolant temperature units configuration changes are saved when exiting this screen. To exit this screen, press and hold interface button for 5 seconds.
Display Screen Contrast Configuration Screen Press and release interface button (Z, Fig. 7) to adjust the screen contrast. Higher Contrast
Lower Contrast
Screen contrast changes are saved when exiting this screen. To exit this screen, press and hold interface button for 5 seconds.
Display Screen Font Size Configuration Screen Press and release interface button (Z, Fig. 7) to adjust the font size. Font size changes are saved when exiting this screen. To exit this screen, press and hold interface button for 5 seconds.
